32 InfraStruXure Power Generation System
Load-Meter
Total Load by Phase
Total Load Summary
Power Factor
Total Load by Phase
Total Load Summary
Power Factor
Sub-Feed Monitoring
For each phase (L1, L2, L3), the following is displayed:
kVA The apparent power provided, in kilovolt-amps.
Iout The output RMS load current.
%LD The load as a percentage of the maximum allowable load.
For the total load supported, the following is displayed:
kW The active power drawn by the load, in kilowatts.
kVA The apparent power provided, in kilovolt-amps.
Freq The frequency, in hertz.
PF The power factor, or the ratio between active power and apparent power (kW/kVA), that is
being supplied to the load.
%LD The load as a percentage of the maximum allowable load.
The following power factor data is displayed for each phase (L1, L2, L3):
kVA The apparent power provided, in kilovolt-amps.
kW The active power drawn by the load, in kilowatts.
PF The power factor, or the ratio between active power and apparent power (kW/kVA), that is
being supplied to the load.
