68 InfraStruXure Power Generation System
How to Add Sub-Feed Output Distribution
Circuit Breakers to the ATS
Output distribution circuit breakers available from APC
Electrical
Hazard
The ATS panel bus must be completely de-energized before adding breakers!
Part Number Description Height on Panel
PG1P15AT1B 15A, single-pole breaker, T1 frame 1.00in/25.4mm
PG1P20AT1B 20A, single-pole breaker, T1 frame 1.00in/25.4mm
PG1P25AT1B 25A, single-pole breaker, T1 frame 1.00in/25.4mm
PG1P30AT1B 30A, single-pole breaker, T1 frame 1.00in/25.4mm
PG3P15AT1B 15A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P20AT1B 20A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P25AT1B 25A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P30AT1B 30A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P40AT1B 40A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P50AT1B 50A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P60AT1B 60A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P70AT1B 70A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P80AT1B 80A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P90AT1B 90A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P100AT1B 100 A, three-pole breaker, T1 frame 3.00 in /76.2mm
PG3P125AT3B 125 A, three-pole breaker, T3 frame 4.13in/104.9 mm
PG3P150AT3B 150 A, three-pole breaker, T3 frame 4.13in/104.9 mm
PG3P175AT3B 175 A, three-pole breaker, T3 frame 4.13in/104.9 mm
PG3P200AT3B 200 A, three-pole breaker, T3 frame 4.13in/104.9 mm
PG3P225AT3B 225 A, three-pole breaker, T3 frame 4.13in/104.9 mm
Note
Circuit breaker adapter modules are required when mounting breakers onto the panel bus
in the ATS. Refer to “Circuit breaker adapter modules available from APC” on page 69.
