60 InfraStruXure Power Generation System
How to Recover From a Lost Network
Management Interface Password
1. Select a serial port on your local computer, and disable any service using that port.
2. Connect the configuration cable (APC part # 940-0103) to the selected port on the computer and
to the console port on the ATS monitoring unit .
3. Run a terminal program (such as HyperTerminal
®
) on your computer and configure the port as
follows:
– 9600 bps
– 8 data bits
– no parity
– 1 stop bit
– no flow control
4. Press E NTER , repeatedly if necessary, to display the User Name prompt. If you are unable to
display the User Name prompt, verify the following:
– The serial port is not in use by another application.
– The terminal settings are correct as specified in step 3.
– The correct cable is being used as specified in step 2.
5. Press the Reset button on the ATS monitoring unit. The Status LED will flash alternately
orange and green. Press the Reset button on the ATS monitoring unit again while the LED is
flashing to temporarily reset the user name and password to their defaults.
6. Press E NTER as many times as necessary to redisplay the User Name prompt, then use the
default apc for the user name and the password (if you take longer than 30 seconds to log on
after the User Name prompt is redisplayed, you must repeat step 5 and log on again).
7. From the Control Console menu, select System, then User Manager.
8. Select Administrator and then change the User Name and Password settings, both of which
are now defined as apc.
9. Press C TRL -C and log off before reconnecting any cable you may have disconnected, and before
restarting any service you may have disabled.
Note
Disregard the procedure in this section if the APC InfraStruXure Manager is included
with your system. Refer to the InfraStruXure Manager’s Installation and Quick-Start
Manual for information about recovering from a lost password.
