Configuring the ATS Network Management Interface
56 InfraStruXure Power Generation System
2. Use Ping with a size of 113 bytes to assign the IP address defined by the ARP command. For the
IP address defined in step 1, use one of the following Ping commands:
– Windows command format:
ping 156.205.14.141 -l 113
– LINUX command format:
ping 156.205.14.141 -s 113
3. Use Telnet to access the ATS at its newly assigned IP address. For example:
telnet 156.205.14.141
4. Use apc for both the User Name and the Password.
5. See “Control console” on this page to finish the configuration.
Control console
After logging on at the control console, as described in “Local access to the control console” on
page 55 or “Remote access to the control console” on page 55, proceed as follows:
1. Choose Network from the Control Console menu.
2. Choose TCP/IP from the Network menu.
3. If you are not using a BOOTP or DHCP server to configure the TCP/IP settings, select the
Boot Mode menu. Select Manual boot mode, and then press E SC to return to the TCP/IP menu
(changes will take effect when you log out).
4. Set the System IP , Subnet Mask, and Default Gateway address values.
5. Press C TRL -C to exit to the Control Console menu.
6. Log out (option 4 in the Control Console menu).
Note
If you disconnected a cable during the procedure described in “Local access to the
control console” on page 55, reconnect that cable and restart the associated service.
