Page 27
27
RLC Communications requires the Serial Communications Type Parameter
(tYPE) be set to rLC.
SENDING SERIAL COMMANDS AND DATA TO THE METER
When sending commands to the meter, a string containing at least one
command character must be constructed. A command string consists of a
command character, a value identifier, numerical data (if writing data to the
meter) followed by a command terminator character * or $. The
available as a terminator when Counter C is in the SLAVE mode.
Command Chart
COMMAND DESCRIPTION
NOTES
N
Node (Meter)
Address
Specifier
Address a specific meter. Must be followed by a
two digit node address. Not required when
address = 00.
T
Transmit Value
(read)
Read a register from the meter. Must be followed
by register ID character
V
Value Change
(write)
Write to register of the meter. Must be followed by
register ID character and numeric data.
R
Reset
Reset a register or output. Must be followed by
register ID character.
P
Block Print
Request
Initiates a block print output. Registers are defined
in programming.
Command String Construction
The command string must be constructed in a specific sequence. The meter
does not respond with an error message to invalid commands. The following
procedure details construction of a command string:
1. The first characters consist of the Node Address Specifier (N) followed by a
1 or 2 character address number. The address number of the meter is
programmable. If the node address is 0, this command and the node address
itself may be omitted. For node address 1 through 9, a leading zero character
is not required. (The only exception is a numeric transmission when Counter
C is set for slave mode.) This is the only command that may be used in
conjunction with other commands.
2. After the optional address specifier, the next character is the command
character.
3. The next character is the Register ID. This identifies the register that the
command affects. The P command does not require a Register ID character.
It prints according to the selections made in print options.
4. If constructing a value change command (writing data), the numeric data is
sent next.
5. All command strings must be terminated with the string termination
characters *, $ or when Counter C is set for slave mode
does not begin processing the command string until this character is received.
See Timing Diagram figure for differences between terminating characters.
Sending Numeric Data
Numeric data sent to the meter must be limited to the digit range shown under
transmit details in the Register Identification Chart. Leading zeros are ignored.
Negative numbers must have a minus sign. The meter ignores any decimal point
and conforms the number to the scaled resolution. (For example: the meter’s
scaled decimal point position = 0.0 and 25 is written to a register. The value of
the register is now 2.5.
Note: Since the meter does not issue a reply to value change commands, follow
with a transmit value command for readback verification.
Register Identification Chart
ID
VALUE
DESCRIPTION
MNEMONIC
COMMAND
TRANSMIT DETAILS
A Count A
CTA
T, V, R
9 positive, 8 ½ negative
B Count B
CTB
T, V, R
9 positive, 8 ½ negative
C Count C
CTC
T, V, R
9 positive, 8 ½ negative
D Rate A
RTA
T
6 digit, positive only
E Rate B
RTB
T
6 digit, positive only
F
Rate C
RTC
T
6 positive, 5 ½ negative
G Max (Hi) Value
MAX
T, V, R
6 positive, 5 ½ negative
H Min (Lo) Value
MIN
T, V, R
6 positive, 5 ½ negative
I
Scale Factor A
SFA
T, V
6 digit, positive only
J
Scale Factor B
SFB
T, V
6 digit, positive only
K Counter Load A
CLA
T, V
6 positive, 5 ½ negative
L
Counter Load B
CLB
T, V
6 positive, 5 ½ negative
M Setpoint 1
SP1
T, V, R
6 positive, 5 ½ negative
O Setpoint 2
SP2
T, V, R
6 positive, 5 ½ negative
Q Setpoint 3
SP3
T, V, R
6 positive, 5 ½ negative
S Setpoint 4
SP4
T, V, R
6 positive, 5 ½ negative
U Auto/Manual
Register
MMR
T, V
0 – auto, 1 - manual
W Analog Output
Register
AOR
T, V
0 – 4095 normalized
X Setpoint Register
SOR
T, V
0 – not active, 1 – active
Command String Examples:
1. Node address = 17, Write 350 to Setpoint 1.
String: N17VM350$
2. Node address = 5, Read Count A value.
String: N5TA*
3. Node address = 0, Reset Setpoint 4 output.
String: RS*
RECEIVING DATA FROM THE METER
Data is transmitted by the meter in response to either a transmit command (T),
a print block command (P) or User Function print request. The response from
the meter is either a full field transmission or an abbreviated transmission. The
meter response mode is selected in Serial Port Parameters (Abrv).
Full Field Transmission (Address, Mnemonic, Numeric data)
Byte
Description
1, 2 2 byte Node Address field [00-99]
3
4-6
3 byte Register Mnemonic field
7-18 12 byte data field, 10 bytes for number, one byte for sign, one byte for
decimal point
19
20
21
22
23
* These characters only appear in the last line of a block print.
The first two characters transmitted are the node address, unless the node
address assigned = 0, in which case spaces are substituted. A space follows the
node address field. The next three characters are the register mnemonic.
The numeric data is transmitted next. The numeric field is 12 characters long
(to accommodate the 10 digit totalizer), with the decimal point position floating
within the data field. Negative values have a leading minus sign. The data field
is right justified with leading spaces.
The end of the response string is terminated with a carriage return
provide separation between the blocks.
