SELECT PARAMETER LIST
Two lists of values are available to allow the user to switch between two sets
of Setpoints, Scale Factors, Counter Load values and Units mnemonics. The two
lists are List A and List B. If a user input is used to select the list then List A is
selected when the user input is not active and List B is selected when the user
input is active (maintained action). If a front panel key is used to select the list
then the list will toggle for each key press (momentary action). The display will
only indicate which list is active when the list is changed.
A submenu is used to select whether the programmed Units Mnemonics are
included in the List function. Select YES in the submenu to have different Units
Mnemonics for List A and List B. Select NO to display the same mnemonics
regardless of the list selected.
To program the values for List A and List B, first complete the programming
of all the parameters with List A selected. Exit programming and switch to List
B. Re-enter programming and program the desired values for the parameters
included in the List.
DISPLAY
DESCRIPTION
FACTORY
UNItS
Units Mnemonics
NO
PRINT REQUEST
The meter issues a block print through the serial port when activated, and the
serial type is set to rLC. The data transmitted during a print request and the serial
type is programmed in Port (Serial) module. If the user input is still active after
the transmission is complete (about 100 msec), an additional transmission
occurs. As long as the user input is held active, continuous transmissions occur.
PRINT REQUEST AND RESET DISPLAYS
The meter issues a block print through the serial port when activated just like
the Print Request function. In addition, when activated (momentary action), the
meter performs a reset of the displays configured as YES in the sublist. Both the
Print and Reset actions will only function when the serial type parameter (tYPE)
is set to Red Lion protocol (rLC).
DISPLAY
DESCRIPTION
FACTORY
Cnt A
Counter A
NO
Cnt b
Counter B
NO
Cnt C
Counter C
NO
Hi
Maximum
NO
Lo
Minimum
NO
MAINTAINED (LEVEL) RESET AND INHIBIT
The meter performs a reset and inhibits the displays configured as YES in the
sublist, as long as activated (maintained action).
DISPLAY
DESCRIPTION
FACTORY
Cnt A
Counter A
NO
Cnt b
Counter B
NO
Cnt C
Counter C
NO
Hi
Maximum
NO
Lo
Minimum
NO
MOMENTARY (EDGE) RESET
When activated (momentary action), the meter resets the displays configured
as YES in the sublist.
DISPLAY
DESCRIPTION
FACTORY
Cnt A
Counter A
NO
Cnt b
Counter B
NO
Cnt C
Counter C
NO
Hi
Maximum
NO
Lo
Minimum
NO
INHIBIT
The meter inhibits the displays configured as YES in the sublist, as long as
activated (maintained action).
DISPLAY
DESCRIPTION
FACTORY
Cnt A
Counter A
NO
Cnt b
Counter B
NO
Cnt C
Counter C
NO
Hi
Maximum
NO
Lo
Minimum
NO
STORE DISPLAY
The meter holds (freezes) the displays configured as YES in the sublist, as long
as activated (maintained action). Internally, the counters and max and min values
continue to update.
DISPLAY
DESCRIPTION
FACTORY
Cnt A
Counter A
NO
Cnt b
Counter B
NO
Cnt C
Counter C
NO
Hi
Maximum
NO
Lo
Minimum
NO
STORE AND RESET DISPLAY
The meter holds (freezes) the displays and then performs a reset of the
displays configured as YES in the sublist, as long as activated (maintained
action).
DISPLAY
DESCRIPTION
FACTORY
Cnt A
Counter A
NO
Cnt b
Counter B
NO
Cnt C
Counter C
NO
Hi
Maximum
NO
Lo
Minimum
NO
SETPOINT DEACTIVATE (RESET) MAINTAINED (LEVEL)
The meter deactivates (resets) the setpoint outputs configured as YES in the
sublist, as long as activated (maintained action).
DISPLAY
DESCRIPTION
FACTORY
S1
Setpoint 1
NO
S2
Setpoint 2
NO
S3
Setpoint 3
NO
S4
Setpoint 4
NO
