Red Lion PAX2D - Manual (Page 2)

2
Ordering Information . . . . . . . . . . . . . . . . . . . 2
General Meter Specifications . . . . . . . . . . . . . 3
Optional Plug-In Cards . . . . . . . . . . . . . . . . . . 4
Installing the Meter . . . . . . . . . . . . . . . . . . . . . 5
Setting the DIP Switches . . . . . . . . . . . . . . . . . 5
Installing the Plug-In Cards . . . . . . . . . . . . . . 6
Wiring the Meter . . . . . . . . . . . . . . . . . . . . . . . 6
Front Panel Keys and Display Overview . . . . . 8
PAX2D Display Loops . . . . . . . . . . . . . . . . . . . 9
Programming the PAX2D . . . . . . . . . . . . . . . . 9
Serial Communications . . . . . . . . . . . . . . . . . 25
PAX2D Modbus Register Table . . . . . . . . . . 26
Factory Service Operations . . . . . . . . . . . . . 37
Troubleshooting Guide . . . . . . . . . . . . . . . . . 38
Parameter Value Chart . . . . . . . . . . . . . . . . . 38
Programming Quick Overview. . . . . . . . . . . . 42
T
able
O
f
C
OnTenTs
O
rdering
i
nfOrmaTiOn
Meter Part Numbers
MODEL NO. DESCRIPTION PART NUMBER
PAX2D Digital Input Panel Meter PAX2D000
Option Card and Accessories Part Numbers
TYPE MODEL NO. DESCRIPTION PART NUMBER
Optional
Plug-In
Cards
PAXCDS
Dual Setpoint Relay Output Card PAXCDS10
Quad Setpoint Relay Output Card PAXCDS20
Quad Setpoint Sinking Open Collector Output Card PAXCDS30
Quad Setpoint Sourcing Open Collector Output Card PAXCDS40
PAXCDC 1
RS485 Serial Communications Card with Terminal Block PAXCDC10
Extended RS485 Serial Communications Card with Dual RJ11 Connector PAXCDC1C
RS232 Serial Communications Card with Terminal Block PAXCDC20
Extended RS232 Serial Communications Card with 9 Pin D Connector PAXCDC2C
DeviceNet Communications Card PAXCDC30
Profibus-DP Communications Card PAXCDC50
PAXCDL Analog Output Card PAXCDL10
Accessories
SFCRD 2 Crimson PC Configuration Software for Windows 2000, XP and Windows 7 SFCRD200
CBLUSB USB Programming Cable Type A-Mini B CBLUSB01
Notes:
1. For Modbus communications use RS485 Communications Output Card and configure communication (tYPE) parameter for Modbus.
2. Crimson software is available for free download from http://www.redlion.net/
