Appendix D ______________________________________________________ Sensor Status Values
VAISALA ______________________________________________________________________ 293
APPENDIX D
SENSOR STATUS VALUES
This chapter contains sensor status values.
Table 121 Sensor Status List
Value Description Notes
0 Sensor is working properly (OK).
1 Not measured yet.
2 Interface is not initialized. 1
3 Communication timeout has occurred. 1
4 Unknown data is received. 1
5 Communication is functioning, but the sensor reports
errors. Use sensor's own service interface to find out the
cause. 1
6 Sensor communication is paused because service
connection is opened. 1
7 Message sequence numbers are overlapping in the
Autotrac satellite transceiver interface. 1
8 ... 19 Not available.
20 Excitation failure is caused by overload in the excitation
output. 1
21 The input voltage is out of range or the A/D conversion
has failed due to an internal error. 2
22 Sensor is disconnected or the connection cables are
broken. 2
23 Sensor output exceeds the min/max limits defined in the
Measurements view. 2
24 Change in sensor output has exceeded the maximum
step defined in the Measurements view. 2
25 An internal configuration error has occurred. 2
26 Error in reference measurement, usually caused by
damaged sensor/logger or electrical interference. 2
27 Internal voltage error occurred or the logger is damaged. 2
28 BARO-1 calibration data error. 2
29 Data is invalid for unspecified reason. 2
30 The measurement or the sensor has been manually
disabled.
99 Sensor status is not supported.
1 Value is available only for sensors with a serial interface.
2 Value is available only for sensors with a conventional, that is, analog or
counter/frequency interface.
