Chapter 8 ____________________________________________________________ Technical Data
VAISALA ______________________________________________________________________ 259
1004-117
Figure 136 Mounting Kit FIX70 Dimensions in Millimeters
Rain Gauge RG13(H)
Rain Gauge RG13H features a heating element but otherwise complies
with the same specifications as Rain Gauge RG13.
Table 106
Rain Gauge RG13(H) Specifications
Property Description/Value
Diameter of aperture
225 mm
Area of aperture
400 cm
2
Rainfall capacity
Unlimited
Sensitivity (rainfall per
pulse)
0.2 mm
Dimensions (height Ø)
390 300 mm
Weight 2.5
kg
Heater (in RG13H)
38 W/40 VAC
Thermostat operation
Opens at +11 °C (±3 °C)
Closes at +4 °C (±3 °C) (in RG13H)
