File Transfer Protocol (FTP)
FTP enables QML logger to send messages as files to FTP server.
Internet
Ethernet LAN
Firewall FTP Server
ADSL
switch
ISP
(DSLAM)
PSTN
1101-021
Figure 74 Example FTP Transmission
Messages appear in FTP server as single file per message, in the
following directory structure, and named as:
root>
Home>
Name>
Obs_FTP.rep
where
= Root directory defined for FTP server
= User home directory defined for AWS login
= Station name as set to QML logger
= Message creation timestamp UTC
Example filename:
Obs_FTP101123132213.rep
- Message was created at 2010/11/23 13:22:13 UTC
