American Fibertek SM10p-PoE - Manual (Page 92)

Group Table
Configure SNMP v3 group table.
¢ Security Name (User ID): Assign the user name that you have set up in user table.
¢ Group Name: Set up the group name.
¢ Click Add to add context name.
¢ Click Remove to remove unwanted context name.
Access Table
Configure SNMP v3 access table.
¢ Context Prefix: Set up the context name.
¢ Group Name: Set up the group.
¢ Security Level: Set up the access level.
¢ Context Match Rule: Select the context match rule.
¢ Read View Name: Set up the read view.
¢ Write View Name: Set up the write view.
¢ Notify View Name: Set up the notify view.
¢ Click Add to add context name.
¢ Click Remove to remove unwanted context name.
MIBview Table
Configure MIB view table.
¢ ViewName: Set up the name.
¢ Sub-Oid Tree: Fill the Sub OID.
¢ Type: Select the type – exclude or included.
85
