are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable. The
table below shows the 10BASE-T/ 100BASE-TX MDI and MDI-X port pin outs.
Pin MDI-X
1
Signal Name
Receive Data plus (RD+)
MDI Signal Name
Transmit Data plus (TD+)
2 Receive Data minus (RD-) Transmit Data minus (TD-)
3 Transmit Data plus (TD+) Receive Data plus (RD+)
6 Transmit Data minus (TD-) Receive Data minus (RD-)
111
