IP Security
IP security function allows user to assign 10 specific IP addresses that have permission
to access the switch through the web browser for the securing switch management.
¢ IP Security Mode: when this option is in Enable mode, the Enable HTTP Server
and Enable Telnet Server check boxes will then be available.
¢ Enable HTTP Server: when this check box is checked, the IP addresses
among
Security IP1 ~ IP10 will be allowed to access via HTTP service.
¢ Enable Telnet Server: when checked, the IP addresses among Security IP1 ~ IP10
will be allowed to access via telnet service.
¢ Security IP 1 ~ 10: Assign up to 10 specific IP address. Only these 10 IP address
can access and manage the switch through the Web browser
¢ And then, click Apply button to apply the configuration
Note Remember to execute the ‘Save Configuration’ action, otherwise the new
configuration will lose when switch power off.
61
