¢ Console Port to 9-Pin DTE Port on PC
Switch’s 9-Pin Serial
Port
2 RXD
3 TXD
5 SGND
CCITT Signal PC’s
9-Pin
---------RXD ------------
-----------TXD ---------
-----------SGND ----------
DTE Port
3 TxD
2 RxD
5 SGND
100BASE-TX/10BASE-T Pin Assignments
With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data,
and
pins 3 and 6 for receiving data; pins 4, 5, 7 and 8 are used for power supplying.
RJ-45 Pin Assignment of non-802.3af standard PD with
Midspan/Endspan POE HUB/SWITCH
¢ Pin out of Cisco non-802.3af standard PD
Pin
1
2
3
4
5
6
7
8
109
Signal
RX+
RX-
TX+
VCC -
VCC -
TX-
VCC +
VCC +
