Appendix
Console Port Pin Assignments
The DB-9 serial port on the switch is used to connect to the switch for out-
of-band
console configuration. The console—command line interface can be accessed from a
terminal or a PC running a terminal emulation program. The pin assignments used to
connect to the serial port are provided in the following tables.
DB-9 Console Port Pin Numbers
¢ DB-9 Port Pin Assignments
Switch’s
PC DB9
EIA Circuit CCITT Signal Description DB9 DTE
DTE Pin #
Pin #
RxD (Received
BB
BA
AB
104
103
102
Data)
TxD (Transmitted
Data)
SGND (Signal
Ground)
108
2
3
5
2
3
5
