certain period (for details, see the IEEE 802.3af specification).
¢ Capacitive Detection: If the port and capacitive detection are enabled, the
capacitances state reads in the voltage result from the constant current. This is the
subtracted from the pre-capacitance voltage to get a charge rate. If this charge rate
is within the window of the PD signatures, the device is considered to be discovered.
¢ And then, click Apply to carry into effect.
¢ Port: The index of PoE ports.
¢ Enable State: Check it to enable the PoE function to the port.
¢ Power Limit From: Check it to decide the power limit method.
‹ Classification: When this check box is marked, the system will limit the power
supply to the powered device in accordance with the related class.
¢ Legacy: Check it to support the legacy power devices.
¢ Priority: Pull down the selection menu item to choose the priority of power
supplying.
¢ Port Limit (<15400) mW: User can key in the power limit value which is under 15.4
Watts.
¢ Mode: Displays the operating mode of the port.
¢ Current (mA): Displays the operating current of the port.
¢ Voltage (V): Displays the operating voltage of the port.
¢ Power (mW): Displays the power consumption of the port.
¢ Determined Class: Displays the PD’s class.
¢ And then, click Apply to carry into effect.
Factory Default
Reset switch to default configuration. Click Reset to reset all configurations
to the default value.
101
