Importing/Exporting Data and Setup Information
when you want to plan and track specific field operations. See Device Setup and About Jobs and Tasks for more
information.
Select an Export Method
Device Setup
Select a Display File Format to Export to
Select a Generic File Format to Export to
Export Settings
Select a topic below on exporting data from the system:
Image Files
Mapped data can be exported as an image file in a bitmap, JPEG, GIF, PNG, or TIFF format. You can export an image
from the management tree or the current map. If you export an image from the management tree the resulting image
will be exported in an un-projected state. If the current map is exported, all its layers will be used to create the image
file and the image will look just like the map was displayed.
Mapped data can also be exported as a GeoTIFF image file. The exported GeoTIFF file contains spatial reference
information that will allow other programs that support GeoTIFF’s to map the image file without requiring
georeferencing information from you. If you export a GeoTIFF from the management tree the resulting image will be
exported in WGS84 Lat/Lon. If the current map is exported, all its layers will be used to create the image file and the
GeoTIFF will be exported in the current projection that the map was set to.
How to export a bitmap or other image file type.
Spatial Files
Selected data in the Management Tree or the current map can be exported as an ESRI Shape file. Not all selections in
the Management Tree or the current map can be exported as a Shape file. The attribute and properties that are
exported can also be customized and export templates can be created for common exports and to speed up exporting.
How to export an ESRI Shape file.
Text Files
Selected data in the Management Tree or the current map can be exported as an ASCII text file. Not all selections in
the Management Tree or the current map can be exported as an ACSII text file. . The attribute and properties that are
exported can also be customized and export templates can be created for common exports and to speed up exporting.
How to export an ASCII text file.
Ag Leader Basic or Ag Leader Advanced Files
Only YLD file based yield data can be exported as an Ag Leader Basic or Advanced file.
How to export an Ag Leader Basic or Advanced format file.
Boundary Files
Any items at or below the Field level can be selected for export as a boundary file. The format of the export file can be
an ESRI Shape, KML, ASCII text, IBY boundary files for the Ag Leader Insight display, or BDY boundary file for use in
the Ag Leader PF3000 or PF3000 Pro. Boundary files can also be exported from the Boundary Edit dialog.
Navigation Files
Navigation datasets that are selected in the Management Tree or the current map can be exported as either an ESRI
Shape, KML, ASCII text, or PFN navigation file for use in the Ag Leader PF3000 or PF3000 Pro. Navigation files can
also be exported from the Navigation Edit dialog.
Prescription Files - Single and Multiple Layer
Prescription datasets that are selected in the Management Tree or the current map can be exported as ESRI Shape,
KML, ASCII text, ARM prescription files for use with Mid-Tech or Tyler/Case IH AIM systems. TGT prescription files for
use in the Ag Leader PF3000/PF3000 Pro or Insight display, IRX files for use in the Insight display, Case IH/New
Holland Voyager PRD, ENS, or PRE prescriptions, or Flexi-Coil PRE prescription files. Prescriptions for the
AGCO/AGCHEM FALCON system can be exported as TIF or TRF/INI file(s). Prescription files can also be exported
from the Prescription Editor dialog.
Single Layer Only
