Table 13 Information Displayed in Prog./Sync Column
Pair Status Information Displayed
Simplex - - - is displayed.
Pending The progress (%) of copying.
Duplex Identical data (%) of S-VOL and T-VOL.
SP-Pend
V-Split
Copy completed data (%).
Split
Resync
Resync-R
Identical data (%) of S-VOL and T-VOL.
Suspend - - - is displayed.
F-Copy Copy completed data (%).
Deleting --- is displayed
• Type: The emulation type of the paired volume.
• Capacity(CYL): The number of cylinders assigned to the volume.
• CTG: The registered ID of the consistency group. If there is no consistency group, --- is displayed.
• CLPR (S): The cache logical partition of the S-VOL is displayed.
• CLPR (T): The cache logical partition of the T-VOL is displayed.
• Relationship(s): The current state of the volume in terms of whether the FlashCopy Mirror V2
relationship is established or not. When no relationship is established, --- is displayed. When
a relationship is established, the status of the volume is displayed as shown in Table 4 2. The
parameter displayed in Relationship(s) changes according to whether the volume is S-VOL or
T-VOL, or if the settings are normal or not.
Table 14 Parameters Displayed in Relationship(s)
Parameter Volume
Settings are Normal Settings are Abnormal
S-VOL S-Normal S-Failed
T-VOL T-Normal T-Failed
Volume set for S-VOL and T-VOL ST-Normal ST-Failed
The information displayed in the information field just below the Volume List is as follows:
• Volume: The total number of volumes defined in the HP StorageWorks XP12000 storage system.
• Pairs: X(Y)/Z, where:
X = total number of Siz pairs.
Y = total number of Siz and Siz pairs.
Z = maximum number of pairs that can be created in one storage system (Siz / XP Auto LUN).
NOTE:
The value (Y) does not include XP Auto LUN, Flex Copy XP, FlashCopy, and XP Snapshot pairs. If
XP Auto LUN, Flex Copy XP, FlashCopy, and XP Snapshot pairs exist, Siz paircreate operation may
fail even when (Y) is less than 8,192.
• Reserved: X(Y)/Z, where:
X = total number of Siz reserved volumes.
Y = total number of Siz and Siz reserved volumes.
Hitachi ShadowImage for z/OS user guide 65
