6.

Touch the

Link Speed

option.

7.

Touch one of the following options.

Setting

Description

Auto

The product automatically configures itself for the highest link speed and
communication mode allowed on the network.

10T Half

10 megabytes per second (Mbps), half-duplex operation

10T Full

10 Mbps, full-duplex operation

100TX Half

100 Mbps, half-duplex operation

100TX Full

100 Mbps, full-duplex operation

100TX Auto

Limits auto-negotiation to a maximum link speed of 100 Mbps

1000T Full

1000 Mbps, full-duplex operation

8.

Touch the

Save

button.

Manually configure IPv6 TCP/IP parameters from the control panel

In addition to using the Embedded Web Server, you can also use the control-panel menus to set an IPv6

address.

1.

At the product control panel, touch the

Administration

button, touch the

Network Settings

menu,

touch the

Embedded Jetdirect Menu

option, touch the

TCP/IP

option, touch the

IPV6 Settings

option, touch the

Address

option, touch the

Manual Settings

option, and then touch the

Enable

option.

2.

Touch the

On

option, and then touch the

Save

button.

3.

Touch the

Address

option, and then touch the data entry field.

4.

Use the keyboard to enter the address, and then touch the

Save

button.

Disable network protocols (optional)

By factory default, all supported network protocols are enabled. Disabling unused protocols has the

following benefits:

Decreases product-generated network traffic

Provides only pertinent information on the configuration page

Allows the product control panel to display protocol-specific error and warning messages

Link speed and duplex settings

The link speed and communication mode of the product must match the network. For most situations,

leave the product in automatic mode. Incorrect changes to the link speed and duplex settings might

prevent the product from communicating with other network devices. If you need to make changes, use

the product control panel.

24

Chapter 3 Administration - Configure the product
