6

Paper stops

7

Automatic document feeder (ADF)

8

ADF output tray

9

ADF input tray

10

Document load/detect LED

11

Paper guides

Back view

1

Power connector

2

Rear panel drawer assembly

3

EIO card slot

4

Formatter status LEDs (both are green; under normal conditions, the left LED is on steady and the right LED blinks)

5

Ethernet port

6

USB host port (under user-removable label)

7

Slot for a cable-type security lock

Sleep Mode

The scanner will enter Sleep Mode after 15 minutes of inactivity. To exit Sleep Mode, do any one of the

following:

Press any button

Touch the touch screen

Lift the flatbed scanner lid

Connect a USB device

4

Chapter 1 Product basics
