Table 3-6

Jetdirect menus (continued)

Menu item

Sub-menu item

Sub-menu item

Values and Description

Ping Test

Dest Type

Select the destination type for this test.

IPV4

(default)

IPV6

Dest IPv4

Enter the IP address for the IPv4 destination.

Dest IPv6

Enter the IP address for the IPv6 destination.

Packet Size

Specify the packet size for this test. Valid values are
64–2048, default is 64.

Timeout

Set the timeout value for this test. Valid values are 1–
100, default is 1.

Count

Set the count value for this test. Valid values are 0 –
100, default is 4.

Print Results

Yes

: Print test results.

No

(default): Do not print test results.

Execute

Yes

: Execute the selected tests..

No

(default): Do not execute the selected tests.

Ping Results

Packets Sent

Number of packets sent. Valid values are 0–65535.

Packets Received

Number of packets received. Valid values are 0–
65535.

Percent Lost

Percent of loss. Valid values are 0–100.

RTT Min

Valid values are 0–4096.

RTT Max

Valid values are 0–4096.

RTT Average

Valid values are 0–4096.

Ping in Progress

Yes

No

20

Chapter 3 Administration - Configure the product
