Chapter 3 Startup and Navigation
26
Toolbar and Icons
FCArray Assistant Client contains a toolbar in the FCArray Assistant window (see
Figure 3-9):
Figure 3-9. Toolbar
Each toolbar button corresponds to a function available from the menu bar:
RAID Assistant: Brings up the RAID Assistant dialog box for FCArray
RAID configurations.
Scan Devices: Scans for new devices recently added and not currently
identified within FCArray Assistant.
Display Controller Information: Displays key information about the
currently selected disk array controller.
Statistics View: Toggles the Statistics View window for the currently
selected disk array controller.
Error Table: Displays a table of bad block and "request sense" data.
Sign On: Enables FCArray Assistant’s configuration and administration
functions to Administrators and monitoring functions to "Users."
Settings: Opens a dialog box for specifying the Alert/Alarm,
Communication, and Event Editor settings that you desire.
Help: Displays FCArray Assistant Client’s on-line help contents page.
