HP Netserver L Server series - Manual (Page 109)

Chapter 5 Monitoring
103
3. Click the Relinquish Partner button to cause this controller’s partner
controller to return to an operating state.
This is required after Expand Array completes.
4. Click the Close button to close the Controller Information window.
Physical Device and Logical Drive Monitoring
Displaying Device Information
The Controller View window details which physical devices are associated with
each controller channel. Each stack of drives represents the physical drives
connected to a single channel on the controller.
A physical device can be a host controller, a CD-ROM drive, disk drive, tape
drive, etc. To see the display information about a particular physical device, do the
following:
•
Double-click a physical device icon in the Controller View window. See
Figure 5-5.
The Device Information property sheet displays. See Figures 5-8 and 5-9.
Figure 5-8. Host Device Information: RAID Controller
