Chapter 3 Startup and Navigation
17
Opening Screen Components
Upon startup (with defined servers), FCArray Assistant Client displays the
opening screen, consisting of the FCArray Assistant window, the Global Status
View window and the Log Information Viewer. See Figure 3-1.
Ж Ж! Ж"
Ж#
Ж$
Ж%
Ж&
Figure 3-1. Opening Screen
Components of the FCArray Assistant Window
The major components of the FCArray Assistant window are described in the
following numbered items. See Figure 3-1.
•
Item #1 - The FCArray Assistant Client menu bar
There are five menus with several selections in each one. The contents of
the menus and the functionality of several of the most important selections
are described throughout this guide.
•
Item #2 - The FCArray Assistant Client toolbar
