Description
Item
Status of external paths.
Status
•
Normal: There are no problems, the system is usable.
•
Disconnect: The path has been intentionally disconnected.
•
Checking: The system is checking the external path status.
•
Unknown: The status of the external path is not known.
•
Warning: There are external paths whose status is not
normal. You can check their status in the View External
LUN Properties window.
•
Blockade: The external path is blocked.
Number of Read/Write commands that can be queued to
the external volume. 8 is set by default.
QDepth
Number of seconds that should pass before I/O to the
external volume times out. 15 seconds is the default.
I/O Timeout (sec.)
Time that will elapse from the time that a path goes down to
the time when the external volume is blocked. 10 seconds is
the default.
Path Blockade Watch(sec.)
When clicked, launches the Disconnect External Paths
window.
Disconnect External Paths
When clicked, launches the Reconnect External Paths window.
Reconnect External Paths
When clicked, launches the Edit External WWNs window.
Edit External WWNs
When clicked, launches the Edit Policies window.
Edit Policies *
When clicked, allows you to save table information to a file.
Export*
* Appears when you click More Actions
Selected external storage system window
Use this window to view information about the selected external storage system.
You can perform these operations from the window:
•
Mapping an external volume (page 30)
•
Adding an external path to an existing path group (page 40)
•
Changing external path priority (page 41)
•
Removing, replacing an external path (page 43)
•
Editing external volume policies (settings) (page 36)
•
Export table information to a file.
Information areas in this window:
•
•
External Path Groups tab (page 85)
