HP1024/HP128 Disk Array
Use the following settings on the external system:
•
The port must be set to the host group for the Windows hosts (host mode 0C: Windows, host
mode 2C: Windows Extension).
•
The port attribute must be set to Target port or RCU target port.
HP512/HP48 Disk Array
Use the following settings on the external system:
•
The port’s host mode must be set to PC Server (0C).
•
The port attribute must be set to Target port or RCU target port.
Thunder 9500V
The following versions are recommended. If you use an earlier version, the SATA drive information
may not display correctly.
•
For Thunder 9530V, Thunder 9520V, Thunder 9570V: version 0658 or later.
•
For Thunder 9580V, Thunder 9585V: version 1658 or later.
The following table shows the system parameters that must be specified for ports on the Thunder
9500V storage system.
Parameter Settings Parameters Window Names
Start Attribute System Startup Settings
Use when the Thunder 9500V is in a one-controller
configuration. Single Mode
Use when the Thunder 9500V is in a two-controller
configuration. Dual Active Mode
Be sure to specify that Data Share Mode will be used.
Do not specify this parameter. Hot Stand-By Mode
Optional Delay Planned Shutdown Common 1
Optional SCSI Fibre Channel Common Options OPTION 1
Optional SCSI Fibre Channel Common Options OPTION 2
Reset of occurred Operation if the processor failure
occurs Data Striping
ON Command Queuing Mode Inquiry Setting
HITACHI (default) Vendor ID
DF600F (default) Product ID
Optional ROM Microprogram Version
Optional RAM Microprogram Version
Optional WEB Title
Reset/LIP Mode Port Type
Optional Reset/LIP Mode (Signal)
Optional. Reset/LIP Mode (Process)
Optional LIP Reset Mode
HP1024/HP128 Disk Array 63
