Configuring the Switch
3-56
VDSL Configuration
You can configure and display communication parameters for VDSL and Ethernet
ports on the switch and connected CPEs.
VDSL Global Configuration
This Web page assigns the same profile to each VDSL switch port. Details of these
profiles are given in the table below.
Notes: 1. The VDSL Intelligent Switch uses Ethernet in the First Mile (EFM), a
VDSL-based technology.
2. A suffix of “A” in the profile name (e.g., S2-16-16A) indicate that this profile is
for both VDSL and ADSL lines in a bundle. Profiles without a suffix of “A” in
the profile name (e.g., S1-16-16) are for VDSL lines only.
3. The following profiles are recommended for use with this switch: S1-16-16,
S2-16-16A, A1-34-11, and A2-34-11A.
Profile Name ProfileType Downstream Rate
(Mbps)
Upstream Rate
(Mbps)
Default Public 1.20 1.40
A1-02OAG-R1 Public 7.56 2.43
A2-02OAG-R1 Public 10.80 2.43
A3-01OAG-R1 Public 17.28 3.78
A4-01OAG-R1 Public 25.92 4.72
S1-03OAG-R1 Public 7.56 7.56
S2-03OAG-R1 Public 10.80 10.40
S3-00OAG-R1 Public 17.28 16.47
S1-16-16 Private 16.74 16.20
S2-16-16A Private 16.74 16.20
A1-34-11 Private 33.75 11.34
A2-34-11A Private 33.75 11.34
A3-25-3 Private 25.38 3.24
A4-45-5 Private 44.55 5.13
A5-50-7 Private 50.49 7.29
A6-22-3A Private 22.55 3.24
A7-40-5A Private 40.91 5.13
A8-46-7A Private 46.44 7.29
TLAN Private 17.01 5.40
Max-Rate Private 71.28 40.50
