Navigating the Web Browser Interface
3-5
Rate Limit 3-50
Input Port Configuration Sets the input rate limit for each port 3-50
Input Trunk Configuration Sets the input rate limit for each trunk 3-50
Output Port Configuration Sets the output rate limit for each port 3-50
Output Trunk Configuration Sets the output rate limit for each trunk 3-50
Port Statistics Lists Ethernet and RMON port statistics 3-51
VDSL 3-56
Global Configuration Batch assigns profiles for speed and distance range to all the
VDSL ports on the switch
3-56
Port Configuration Configures port connection settings 3-58
Port Link Status Displays information on the link status of individual VDSL ports 3-61
Port Ethernet Statistics Displays Ethernet statistics for individual switch VDSL ports and
linked CPE Ethernet ports
3-63
Line Configuration Configures line connection settings 3-65
Interface Information Displays physical interface and channel interface information 3-66
Performance Monitor
Information
Displays line and channel performance data information since
the switch was last reset, during the current 15 minute interval,
and during the current day.
3-69
Performance Monitor History Displays line and channel performance data information during
selected 15 minute intervals over the last 24 hours of switch
operation, and during selected 1-day intervals from the current
day to 30 days ago.
3-72
Address Table 3-73
Static Addresses Displays entries for interface, address or VLAN 3-73
Dynamic Addresses Displays or edits static entries in the Address Table 3-74
Address Aging Sets timeout for dynamically learned entries 3-75
Spanning Tree 3-76
STA 3-76
Information Displays STA values used for the bridge 3-77
Configuration Configures global bridge settings for STA and RSTP 3-79
Port Information Displays individual port settings for STA 3-81
Trunk Information Displays individual trunk settings for STA 3-81
Port Configuration Configures individual port settings for STA 3-84
Trunk Configuration Configures individual trunk settings for STA 3-84
Menu Description Page
