Configuring the Switch
3-38
CLI – This example sets the authentication mode to enable 802.1x on port 2, and
allows up to ten clients to connect to this port.
Displaying 802.1x Statistics
This switch can display statistics for dot1x protocol exchanges for any port.
Statistical Values
Web – Select Security, 802.1x, Statistics. Select the required port and then click
Query. Click Refresh to update the statistics.
Console(config)#interface ethernet 1/2 4-84
Console(config-if)#dot1x port-control auto 4-70
Console(config-if)#dot1x operation-mode multi-host max-count 10 4-70
Console(config-if)#
Parameter Description
Rx EXPOL Start The number of EAPOL Start frames that have been received by this
Authenticator.
Rx EAPOL Logoff The number of EAPOL Logoff frames that have been received by this
Authenticator.
Rx EAPOL Invalid The number of EAPOL frames that have been received by this
Authenticator in which the frame type is not recognized.
Rx EAPOL Total The number of valid EAPOL frames of any type that have been received
by this Authenticator.
Rx EAP Resp/Id The number of EAP Resp/Id frames that have been received by this
Authenticator.
Rx EAP Resp/Oth The number of valid EAP Response frames (other than Resp/Id frames)
that have been received by this Authenticator.
Rx EAP LenError The number of EAPOL frames that have been received by this
Authenticator in which the Packet Body Length field is invalid.
Rx Last EAPOLVer The protocol version number carried in the most recently received EAPOL
frame.
Rx Last EAPOLSrc The source MAC address carried in the most recently received EAPOL
frame.
Tx EAPOL Total The number of EAPOL frames of any type that have been transmitted by
this Authenticator.
Tx EAP Req/Id The number of EAP Req/Id frames that have been transmitted by this
Authenticator.
Tx EAP Req/Oth The number of EAP Request frames (other than Rq/Id frames) that have
been transmitted by this Authenticator.
