Configuring the Switch
3-6
VLAN 3-86
802.1Q VLAN 3-86
Basic Information Displays information on the VLAN type supported by this switch 3-88
Current Table Shows the current port members of each VLAN and whether or
not the port is tagged or untagged
3-89
Static List Used to create or remove VLAN groups 3-91
Static Table Modifies the settings for an existing VLAN 3-92
Static Membership Configures membership type for interfaces, including tagged,
untagged or forbidden
3-93
Port Configuration Specifies default PVID and VLAN attributes 3-94
Trunk Configuration Specifies default trunk VID and VLAN attributes 3-94
Private VLAN 3-96
Private VLAN Status Enables or disables the Private VLAN feature 3-97
Private VLAN Link Status Configures ports as downlink or uplink ports. Traffic from
downlink ports can only be forwarded to, and from, the uplink
ports
3-97
Priority 3-98
Default Port Priority Sets the default priority for each port 3-98
Default Trunk Priority Sets the default priority for each trunk 3-98
Traffic Classes Maps IEEE 802.1p priority tags to output queues 3-100
Traffic Classes Status Enables/disables traffic class priorities (not implemented) NA
Queue Mode Sets queue mode to strict priority or Weighted Round-Robin 3-101
Queue Scheduling Configures Weighted Round Robin queueing 3-102
IP Precedence/
DSCP Priority Status
Globally selects IP Precedence or DSCP Priority, or disables
both.
3-103
IP Precedence Priority Sets IP Type of Service priority, mapping the precedence tag to
a class-of-service value
3-104
IP DSCP Priority Sets IP Differentiated Services Code Point priority, mapping a
DSCP tag to a class-of-service value
3-105
IP Port Priority Status Enables/disables Port Priority status 3-107
IP Port Priority Maps IP ports (TCP/UDP ports) to the switch’s 4 traffic class
queues
3-107
Copy Settings Allows you to copy the priority settings from a selected port or
trunk to another selected port or trunk
3-108
Menu Description Page
