Configuring the Switch
3-10
CLI – Use the following command to display version information.
Displaying Bridge Extension Capabilities
The Bridge MIB includes extensions for managed devices that support Multicast
Filtering, Traffic Classes, and Virtual LANs. You can access these extensions to
display default settings for the key variables.
Field Attributes
• Extended Multicast Filtering Services – This switch does not support the
filtering of individual multicast addresses based on GMRP (GARP Multicast
Registration Protocol).
• Traffic Classes – This switch provides mapping of user priorities to multiple
traffic classes. (Refer to “Class of Service Configuration” on page 3-98.) Note
that Traffic classes is always enabled in this switch, it cannot be disabled.
• Static Entry Individual Port – This switch allows static filtering for unicast and
multicast addresses. (Refer to “Setting Static Addresses” on page 3-73.)
• VLAN Learning – This switch uses Independent VLAN Learning (IVL), where
each port maintains its own filtering database.
• Configurable PVID Tagging – This switch allows you to override the default
Port VLAN ID (PVID used in frame tags) and egress status (VLAN-Tagged or
Untagged) on each port. (Refer to “VLAN Configuration” on page 3-86.)
• GMRP – GARP Multicast Registration Protocol (GMRP) allows network devices
to register endstations with multicast groups. This switch does not support
GMRP; it uses the Internet Group Management Protocol (IGMP) to provide
automatic multicast filtering.
Console#show version 4-54
Unit1
Serial number :
Service tag :
Hardware version :
Module A type :not present
Module B type :not present
Number of ports :12
Main power status :
Redundant power status :
Agent(master)
Unit id :1
Loader version :2.0.0.2
Boot rom version :2.0.1.9
Operation code version :1.0.3.5
Console#
