1-1
Chapter 1: Introduction
The switch provides a broad range of features for Layer 2 switching. It includes a
management agent that allows you to configure the features listed in this manual.
The default configuration can be used for most of the features provided by this
switch. However, there are many options that you should configure to maximize the
switch’s performance for your particular network environment.
The switch uses four frequency bands (two downstream and two upstream) for
VDSL lines. These frequency bands conform to ANSI Plan 998. Details of the
frequency bands are given in the table below.
Key Features
Feature Description
4-Band VDSL Total Bandwidth: 11.1 MHz
Bandwidth Allocation: Downstream 1 (0.9-3.75 MHz),
Downstream 2 (5.2-8.5 MHz), Upstream 1 (3.75-5.2 MHz),
Upstream 2 (8.5-12 MHz)
Configuration Backup
and Restore Backup to TFTP server
Authentication Console, Telnet, web – User name / password, RADIUS,
TACACS+
Web – HTTPS; Telnet – SSH
SNMP – Community strings, IP address filtering
Port – IEEE 802.1x, MAC address filtering
DHCP Client Supported
Port Configuration Speed, duplex mode and flow control
Rate Limiting Input and output rate limiting per port
Port Mirroring One or more ports mirrored to single analysis port
Port Trunking Supports 1 Gigabit trunk using either static or dynamic trunking
(LACP)
Broadcast Storm
Control Supported
Static Address Up to 8K MAC addresses in the forwarding table
IEEE 802.1D Bridge Supports dynamic data switching and addresses learning
Store-and-Forward
Switching Supported to ensure wire-speed switching while eliminating bad
frames
Spanning Tree
Protocol Supports standard STP and Rapid Spanning Tree Protocol
(RSTP)
