NORD CON Manual
52 BU 0000 GB
Name Description
Open A stored measurement data file can be chosen and loaded. During loading there is the choice if
only the setting should be loaded or all data of measurement.
Save as The present measurement data and settings are saved with new name.
Export The data can be exported as graphic file or data table.
Print The lines of measurement are printed with present settings (colour of background: white).
Scope Offline
In Offline-mode (no inverter is connected) a saved measurement file can be loaded by
menuitem
File|Open .
8 Macro editor
The macro editor is designed in order to provide simple process cycles. The surface offers the
possibility to create a macro by popup menus, toolbars or tool window. The individual
instructions can be shifted by drag n drop in the opinion. The built-in functions, as memory and
shop macros are integrated likewise into the popup menu. The macros are stored in the
standard format „XML ". The format of the previous version can be imported over the menu
option "opening" type of file „macro files V1.27".
8.1 Graphic user interface
More views are required for handling of the macro generator additionally to the editor window.
These views are available as tool windows. These windows can be docked or undocked to the
edge of the main window. With the menu option „view" of the popup menu all views can be
opened and closed.
Window "Variables"
Window "Properties"
Window "Log"
8.1.1 Window "Variables"
The view „variables" can be opened and closed over the menu option „View->Macro->Variables
". It is used for debugging. In this window after starting macros all variables and objects macros
with current rating are indicated. The expenditure of the value can be stopped in the view
„Properties->Display format".
There are the following formatting:
Decimal
