Futek Advanced Sensor Technology – Futek VCal™Documentation Rev. 1.8.0 07/26/05
©Futek Advanced Sensor Technology 2005 58
Physical Specifications :
• Length – 12
3/8
in or (31.5 cm)
• Width – 6 in or (15.24 cm)
• Height – 1
5/8
in or (4.06 cm)
• Weight – 2.8 lbs. or (1.27 kg)
VCal™Data Acquisition Module Specifications :
• Resolution: ± 20 bits
• Input range: ± 4.5mV/V
• Analog input range: ±15 VDC, 4 – 20 mA
• Power Supply Output: 15 VDC @ 2A
• Default Shunt Cal Values: 60.4KΩ, 100KΩ, and 150KΩ (Other Shunt Values available per customer request)
• Measuring rate: 4.7 to 600 Hz
• Filter frequency: 0.25 to 40 Hz
• Storage Temperature: 0 to 60° C (32 to 140° F)
• Temperature Probe Range: -55 to 125° C (-67 to 257° F)
• Sensor Connection: 4 wire
• Fuse: 250V @
VI. Futek VCal™Specification Page
