OPERATION
6
53
OPTISONIC 6300 P
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
• Select Graphical page
• Parameter: Select the parameter to be shown in the graph (Volume flow, Velocity of Sound or
Temperature).
• Range 0% / 100%: Program the minimum and maximum value of the measurement
• Minimum scale / maximum scale: Program the minimum and maximum value of the axis in
the graph.
• Low flow cutoff threshold / hysteresis: Use the default values.
• Time constant: Only change the default value to a higher value if the signal is unstable.
6.1.2 Basic settings of display
To change the brightness of the display, go to menu 2.4.3.2
• Brightness: Set the percentage of the maximum brightness.
• Sleep time: Set the time after which the display turns off if no key is pressed.
2.4.3.1.4
None (cyclic)
1st meas. page
2nd meas. page
Graphical page Graphical page Graphical page Graphical page
Status page
13-04-2010 14:11:09 13 MB free
2.4.3.1.3
Parameter Parameter Parameter Parameter
Range 0%
Range 100%
Minimum scale
Maximum scale
Low flow cutoff threshold
low flow cutoff hysteresis
Time constant
Volume flow Volume flow Volume flow Volume flow
0.000 m3/h
540.0 m3/h
-120 %
120 %
0 %
0 %
0.1 %
13-04-2010 14:11:09 13 MB free
INFORMATION!
Additional screens showing trend graphs in measuring mode can be setup at the datalogger set
up, go to "Measurement Setup Logger Logger setup View log in screens".
2.4.3.2
Brightness Brightness Brightness Brightness
Sleep time
50 % 50 % 50 % 50 %
60 s
13-04-2010 14:11:09 13 MB free
CAUTION!
Setting the brightness to 100% instead of 50% decreases the total operating time approximate
5%.
