ELECTRICAL CONNECTIONS
5
43
OPTISONIC 6300 P
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
5.3 Power supply
Plug in the connector of the supplied charger at the connector 1. Then insert the main power
connector into your mains outlet.
5.4 Signal cable
WARNING!
Only use the supplied AC charger to charge the battery of the converter!
1 2
USB i/o
DC in
1
CAUTION!
The battery status indicator will be accurate after an initial full discharge directly followed by a
full charge of the battery.
CAUTION!
Find the calibration numbers that are noted on the labels on the cable of each transducer. Make
sure that both transducers have the same calibration number as shown by the converter.
INFORMATION!
The signal cables are prefixed to the transducers in the factory.
