AC Characteristics
True RMS AC
Voltage
Range Frequency
1 Year
23˚C ± 5˚C Temperature
Coefficient/˚C
200.0000 mV
45 Hz - 2 kHz
2 kHz - 10 kHz
10 kHz - 20 kHz 0.5 + 0.05
1.0 + 0.05
2.0 + 0.10
0.005 + 0.005
2.000000 V 0.005 + 0.005
20.00000 V 0.005 + 0.005
200.0000 V 0.005 + 0.005
600.000 V 0.005 + 0.005
Accuracy specification : ± (% of reading + % of range)
True RMS AC
Current
Range Frequency
1 Year
23˚C ± 5˚C Temperature
Coefficient/˚C
(AC+DC) 30.00000 mA
45 Hz - 2 kHz
2 kHz - 10 kHz 0.5 + 0.05
1.0 + 0.05
0.03 + 0.006
300.0000 mA 0.03 + 0.006
3.000000 A 0.03 + 0.006
30.00000 A
45 Hz - 400 Hz 0.5 + 0.05
0.03 + 0.006
300.0000 A 0.03 + 0.006
Accuracy specification : ± (% of reading + % of range)
Current Monitor Accuracy
Range Shunt Value DC Accuracy
AC Accuracy
≦
400 Hz
Max Input
DC/AC rms
30.00000 mA 10 Ω 0.01% 0.1% 30 mA
300.0000 mA 1 Ω 0.01% 0.1% 300 mA
3.000000 A 0.1 Ω 0.01% 0.1% 3 A
30.00000 A 0.01 Ω 0.01% 0.1% 30 A
300.0000 A 0.001 Ω 0.02% 0.1% 300 A
