PCS-1000 User Manual

36

Setting the GPIB Address

Background

The GPIB port is used for remote control. The
GPIB address can be set between 00 ~ 30.

See the Communication Interface chapter on
page 42 chapter for details on remote control.

Steps

1. Long push the Func key.

The function menu will appear.

2. Use the ◄ Func ► keys to navigate to the

ADDRESS settings.

3. Use the ▼Select ▲ keys to select the GPIB

address. Press the Enter key to set the address.

4. Use the ◄ Func ► keys to navigate to the

SAVE FUNC SET menu item. Press the Enter
key to save.

Note

To exit without saving, navigate to the

EXIT FUNC

SET

menu using the ◄

Func

► keys and press the

Enter

key to exit without saving any settings.
