GETTING STARTED
9
PCS-1000 Overview
The PCS-1000 uses five high-precision shunt resistors as the basis
for accurate current and voltage measurements. The 5 shunt ranges
are 0.001Ω, 0.01Ω, 0.1Ω, 1Ω, 10Ω with a current measurement range
of 300A, 30A, 3A, 300mA and 30mA, respectively.
Main Features
Performance  Wide DC/AC voltage range
(200mV ~ 600VAC/1000VDC)
 Wide AC/DC current range (30mA ~ 300A)
 Low drift at all ranges
 Low temperature coefficients
Features  Shunts: 0.001Ω, 0.01Ω, 0.1Ω, 1Ω, 10Ω
 Current Meter (6 1/2 digits current meter)
 Voltage Meter (6 1/2 digits voltage meter)
 Current Monitor
 Voltage and current can be measured at the
same time.
Interface  USB
 GPIB for SCPI commands
