AFG-2000 Series User Manual
18
Q
UICK REFERENCE
This chapter lists operation shortcuts and default factory settings.
Use this chapter as a handy reference for instrument functions. This
chapter is to be used as a quick reference; for detailed explanations
on parameters, settings and limitations, please see the operation
chapter (page 34) or specifications (page 137).
How to use the Digital Inputs ............................................ 19
Selecting a Waveform ........................................................ 21
Sine Wave ............................................................................. 21
Square Wave ........................................................................ 21
Ramp Wave .......................................................................... 22
ARB ................................................................................... 23
ARB - Points ......................................................................... 23
Modulation ........................................................................ 24
AM (2100 series only) .......................................................... 24
FM (2100 series only) .......................................................... 25
FSK Modulation (2100 series only) ..................................... 26
Sweep (2100 series only) ................................................... 28
Counter (2100 series only) ................................................ 30
Save/Recall ........................................................................ 31
Save ...................................................................................... 31
Recall .................................................................................... 31
Default Settings ................................................................. 32
