REMOTE INTERFACE

99

-5V ~ +5V (50Ω)

*AFG-2005/2105 limited to 5MHz, AFG-2012/2112
limited to 12MHz.

Example

SOURce1:APPL:SQU MAX, DEF, DEF

Outputs a 100mVpp (DEF) square wave at 25MHz
with 0 offset (DEF).

SOURce[1]:APPLy:RAMP

Set

Description

Outputs a ramp wave when the command has
executed. Frequency, amplitude and offset can also
be set. The symmetry is fixed to 100%.

Syntax

SOURce[1]:APPLy:RAMP [ [,
[,] ]]

Parameter

0.1Hz~1MHz

<

amplitude

>

1mV~10V (50Ω)

-5V ~ +5V (50Ω)

Example

SOUR1:APPL:RAMP 2KHZ,MAX,MAX

Sets the frequency to 2kHz and sets the amplitude
and offset to the maximum.

SOURce[1]:APPLy:NOISe

Set

Description

Outputs Gaussian noise with a 20 MHz
bandwidth. Amplitude and offset can also be set.

Note

The Frequency parameter is not used with the
noise function; however a value (or DEFault) must
still
be specified. The frequency is remembered for
the next function used.

Syntax

SOURce[1]:APPLy:NOISe [
[, [,] ]]

Parameter

0.1Hz~25MHz*

1mV~10V (50Ω)
