AFG-2000 Series User Manual
106
The maximum amplitude that can be set for the
current function is 5 volts.
SOURce[1]:DCOffset
Set
Query
Description Sets or queries the DC offset for the current mode.
Note
The offset parameter can be set to MINimum or
MAXimum. The default offset is 0 volts. The offset
is limited by the output amplitude as shown
below.
|Voffset| < Vmax – Vpp/2
If the output specified is out of range, the
maximum offset will be set.
The maximum offset is ±5V into 50Ω).
Syntax SOURce[1]:DCOffset {< offset>
|MINimum|MAXimum}
Example SOUR1:DCO MAX
Sets the offset to the maximum for the current
mode.
Query Syntax SOURce[1]:DCOffset? {MINimum|MAXimum}
Return Parameter Returns the offset for the current mode.
Query Example SOUR1:DCO?
>+3.0000E+00
The offset for the current mode is set to +3 volts.
SOURce[1]:SQUare:DCYCle
Set
Query
Description Sets or queries the duty cycle for square waves
only. The setting is remembered if the function
mode is changed. The default duty cycle is 50%.
Note
The duty cycle of square waveforms depend on the
frequency settings.
