GDS-1000A-U Programming Manual
72
1 CH1 2 CH2
3 Math 4 RefA
5 RefB
Example :memory1:save:waveform 1 Saves the CH1
waveform to the
internal memory W1
*RCL
Set
Description Recalls a set of panel setting from one of the fifteen
internal memories, S1 to S15.
Same as: Save/Recall key (recall) → F3
Syntax *rcl
Parameter Settings
1 to 15 S1 to S15
Example *rcl 1 Recalls the panel settings
from S1
:REF:DISPlay
Set
Query
Description Recalls a reference waveform into the display or
returns its status.
Same as: Save/Recall key (recall) → F5 → F2 or F3
Syntax < Long > < Short >
:ref:display
:ref:display? :refdisp
:refdisp?
Parameter Reference Reference on/off
1 A 0 off
2 B 1 on
Example :ref1:display 1 Turns on the reference
waveform A
