COMMAND DETAILS
17
Example *lrn?
:DISPlay:WAVeform 0;ACCumulate 0;CONTrast 0;GRATicule
0;:CHANnel1:DISPlay 1;BWLimit 0;COUPling 0;INVert
0;OFFSet 1.360e+00;PROBe 3;SCALe
2.000e+00;:CHANnel2:DISPlay 1;BWLimit 0;COUPling
0;INVert 0;OFFSet 5.000e-02;PROBe 3;SCALe 5.000e-
02;:CHANnel1:MATH 0;:TIMebase:SWEep 0;SCALe 2.500e-
08;DELay 0.000e+00;WINDow:SCALe 1.00000e-09;DELay
0.00000e+00;:ACQuire:MODe 0;AVERage 0;:TRIGger:TYPe
0;SOURce 0;MODe 1;SLOP 0;COUPle 1;REJect 0;NREJ 0;LEVel
2.32000e+00;PULSe:MODe: 0;TIMe 0.00000e+00;:VIDeo:TYPe
1;POLarity 1;FIELd 1;LINe 1;:CURSor:SOURce 1;XDISPlay
0;X1Position 75;X2Position 175;YDISPlay 0;Y1Position
54;Y2Position 154;:REF1:DISPlay 0;LOCate 71;:REF2:DISPlay
0;LOCate 50;:RUN
*RST
Set
Description Resets the GDS-1000A (recalls the default panel
settings).
Same as: Save/Recall key → F1
Syntax *rst
:SYSTem:ERRor
Query
Description Returns the oscilloscope system error messages, if
there are any.
Syntax < Long > < Short >
:system:error? :syst:err?
Parameter ID Contents ID Contents
-100 command error -102 syntax error
-220 parameter error -221 settings conflict
-222 data out of range -223 too much data
-224 illegal parameter -232 invalid format
Example :system:error?
-102 Indicates that the
command syntax is
wrong
