GDS-1000A-U Programming Manual
62
:TEMPlate:MIN
Set
Query
Description Sets or queries the template used for the MIN
boundary (W1~W15, RefB).
Note A template can only be defined for the MAX or
MIN template, not both.
Before this command can be used, please set the
template mode to normal using
the :TEMPlate:MODe 0 command.
Before any Go-NoGo command can be used,
please use the :GONogo:FUNCtion 1 command to
initialize the oscilloscope.
Syntax < Long > < Short >
:TEMPlate:MIN
:TEMPlate:MIN? :TEMP:MIN
:TEMP:MIN?
Parameter/
Return parameter 0 Set RefB as the MIN template.
1~15 Set W1 ~ W15 as the MIN template
Example :TEMP :MIN ?
>1 RefB is the template.
:TEMPlate:POSition:MAX
Set
Query
Description Sets and queries the position of the MAX template
in grid divisions. 1 grid division = 25 on-screen
pixels.
