GDS-1000A-U Programming Manual
46
:MEASure:FRRDelay
Query
Description Returns the delay between the first rising edge of
source1 and the first rising edge of source2.
Same as: Measure key → F1~F5 →Select delay
measurement function by VARIABLE knob
Syntax < Long > < Short >
:measure:frrdelay? :meas:frrd?
Returns
Note Select the two delay channels before entering this
command: :measure:delay1
and :measure:delay2 .
Example
:
measure:delay1 1
:measure:delay2 2
:measure:frrdelay?
Select channel 1 and 2
as delay source1/2,
and then measure
FRR.
:MEASure:LFFDelay
Query
Description Returns the delay between the first falling edge of
source1 and the last falling edge of source2.
Same as: Measure key → F1~F5 →Select delay
measurement function by VARIABLE knob
Syntax < Long > < Short >
:measure:lffdelay? :meas:lffd?
Returns
Note Select the two delay channels before entering this
command: :measure:delay1
and :measure:delay2 .
Example :measure:delay1 1
:measure:delay2 2
:measure:lffdelay? Select channel 1 and 2
as delay source1/2,
and then measure
LFF.
