COMMAND DETAILS
31
Math Command
:MATH:OPERator ........................................................31
:MATH:POSition ..........................................................31
:MATH:FFT:SOURce ...................................................32
:MATH:FFT:WINDow ..................................................32
:MATH:FFT:SCALe .......................................................33
:MATH:FFT:HORizontal:SCALe ..................................33
:MATH:FFT:HORizontal:POSition ..............................33
:MATH:OPERator
Set
Query
Description Sets the math operator.
Syntax < Long > < Short >
:MATH:OPERator
{PLUS|0|MINUS|1|MUL|2|FFT|
3|FFTRMS|4}
:MATH:OPERator? :MATH:OPER
{PLUS|0|MINUS|1|MU
L|2|FFT|3|FFTRMS|4}
:MATH:OPER?
Parameters PLUS|0 Addition MINUS|1 Subtraction
MUL|2 Multiplication FFT|3 FFT
FFTRMS|4 FFTRMS
Example :MATH:OPER PLUS Sets the operator to
addition.
:MATH:POSition
Set
Query
Description Sets or vertical position (in grid divisions) of the
math output waveform.
Syntax < Long > < Short >
:MATH:POSition
:MATH:POSition? :MATH:POS
:MATH:POS?
