COMMAND DETAILS
29
:CHANnel:PROBe:RATio
Set
Query
Description Sets or returns the probe attenuation factor.
Same as: Channel key → variable knob
Syntax < Long > < Short >
:channel:probe:ratio
:channel:probe:ratio? :chan:prob:rat
:chan:prob:rat?
Parameter Channel Probe
attenuation
factor
1/2 CH1/2 0.1/0.2/0.5 0.1x/0.2x/0.5x
1/2/5 1x/2x/5x
10/20/50 10x/20x/50x
100/200/500 100x/200x/500x
1000/2000 1000x/2000x
Example :channel1:probe:ratio 1 Sets the Channel 1
probe attenuation
factor to 1x
:CHANnel:PROBe:TYPE
Set
Query
Description Sets or returns the probe type (voltage/current).
Same as: Channel key →F4
Syntax < Long > < Short >
:channel:probe:type
:channel:probe:type? :chan:prob:type
:chan:prob:type?
