GDS-1000A-U Programming Manual
28
:channel:math
:channel:math? :chan:math
:chan:math?
Parameter Channel Math operation
1/2 CH1 or CH2 0 Math off
1 Add
2 Subtract
3 Multiply
4 FFT
5 FFTrms
Example1 :channel1:math 2 Channel 1 – Channel 2
Example2 :channel2:math 4 Runs FFT on Channel 2
:CHANnel:OFFSet
Set
Query
Description Sets or returns the offset level for a channel. The
offset level range depends on the vertical scale.
Syntax < Long > < Short >
:channel:offset
:channel:offset? :chan:offs
:chan:offs?
Parameter Channel Offset level
1/2 CH1/2 ±0.5~
±5 ±0.5V ~ ±5V
(2mV/div~50mV/div)
±5.0~
±50 ±5.0V ~ ±50V
(100mV/div~500mV/div)
±50.0~
±300 ±50.0V ~ ±300V
(1V/div ~ 10V/div)
Example :channel1:scale 1.00e–2
:channel1:offset 2.00e–2 Sets the Channel 1
scale to 10mV/div
Sets the Channel 1
offset to 20mV
