GDS-1000A-U Programming Manual
48
:MEASure:LRRDelay
Query
Description Returns the delay between the first rising edge of
source1 and the last rising edge of source2.
Same as: Measure key → F1~F5 →Select delay
measurement function by VARIABLE knob
Syntax < Long > < Short >
:measure:lrrdelay? :meas:lrrd?
Returns
Note Select the two delay channels before entering this
command: :measure:delay1
and :measure:delay2 .
Example :measure:delay1 1
:measure:delay2 2
:measure:lrrdelay? Select channel 1 and 2
as delay source1/2,
and then measure
LRR.
:MEASure:FOVShoot
Query
Description Returns the fall overshoot amplitude.
Same as: Measure key → F1~F5 → F3 (FOVShoot)
Syntax < Long > < Short >
:measure:fovshoot? :meas:fovs?
Returns with % sign
Note Before using this command, select the
measurement channel. See the example below.
Example :measure:source 1
:measure:fall? Selects Channel 1, and
then measures the fall
overshoot.
